Beiene Intelligent Automatic Smart Hydraulic CNC Multifunction Busbar Processing Machine

Overview

Basic Info.

Model NO.	BPM-303CNC-8S
Number of Hydraulic Units	3*31.5
Number of Motors	3+1
Transport Package	Export Standard Free-Fumigation Wooden Case
Specification	Machine Weight: 1500kg
Trademark	BEIENE
Origin	Shandong, China
Production Capacity	200sets Per Month

Product Description

Multifunction Busbar Processing Machine

Our Advantages

1.The Shearing Unit adopts overall structure, its design is new and unique, proper stress, which guarantee long time usage without deformation.

2.The Bend Unit adopts overall structure,angular CNC method, operation is simple and highly accurate.3.The machine adopts double layer platforms design scheme,three units can be operated at the same time.4.The machine is equipped with auto refueling and draining system.5.The machine adopts stainless steel oil tank,so no corrosive degeneration of the hydraulic oil and extension the usage life span of hydraulic oil and each sealing parts.6. PLC control, stable and reliable.
Configuration

Workbench(mm)	Weight(Kg)	MotorNumber	MotorPower(KW)	Voltage(V)	HydraulicPressure(Mpa)	Control
Layer11500×1200	1500	3+1	11.37	380	3 × 31.5	PLC+CNCAngle Bending
Layer2840 × 370

Product Parameters

Items	Materials	ProcessingThickness × Width	Maximum punch	Maximum output force(KN)
Punch Unit	Copper/Aluminum	16 x 260mm	¢32	600KN
Shear Unit	Copper/Aluminum	12 × 160mm/15 x 160mm		350KN
Bend Unit	Copper/Aluminum	15 × 160mm/12 x 120mm		350KN
